Standard 5mm TM0105 Probes

Manufacturer: ProvibTech

Product ID: 5mm TM0105-STD

Weight: 1.00 lbs

$233.75

Probe Type|

1.0m Armor

None

NO Armor

Armor (+$32.00)

Unthreaded Length(Imperial)

Unthreaded Length (Metric)

Case Length (Imperial) (max=9.5in)

Case Length (Metric) (Max=250mm)

Total Length

Connector Type

Intended order specs (used to check part number orderd)

E-mail to a friend

The TM0105 (5mm) probes are
designed for long life cycles and are suitable for harsh
environments. ProvibTech realizes one of the most
significant problems in proximity probe installations are
ground loops and loss of isolation due to damaged cable
jackets. ProvibTech’s custom rugged cable jacket prevents
the probe cable from breaking and tearing and is highly
resistive to corrosive environments.

Data Sheet

TM0105	-XX	-XX	-XX	-XX	-XX
Standard 5mm Probe	Probe Type	Unthreaded Length	Case Length	Total Length	Connector Type

1/4”-28UNF; without armor	-1	Standard: 00 (0.0 in) Maximum: Case length-1.0 in Increment: 01 (10mm)	Standard: 20 (2.0 in) Increment: 05 (0.5 in) Minimum: 10 (1.0 in) Maximum: 95 (9.5 in)	05 (0.5m), 10 (1.0m), 50 (5.0m), 90 (9.0m)	00(none), 02(yes)
1/4”-28UNF; with armor	-2
M8×1; without armor	-7	Standard: 00 (0.0mm) Maximum: Case length-20mm Increment: 01 (10mm)	Standard: 05 (50 mm) Increment: 01 (10 mm) Minimum: 02 (20 mm) Maximum: 25 (250 mm)

M8×1; with armor	-8
