Specifications
Mechanical:
Service: Continuous duty underwater, 20 year life.
Depth: 8,000 ft sea water maximum. (IP68, NEMA 6P)
Service temperature: -40°C to 100°C, (-40°F to 212°C)
Vibration Range: 4-20ma output proportional to velocity
Raw Signal: Acceleration, 100mv/g
Accuracy: 2%
Axis orientation: Any
Seismic weight with mating connector (316SS): 925g
Mounted resonate frequency with 1/4NPT stud mount: 5.5 kHz minimum
4-20ma frequency response: 2-1200 Hz, unfiltered.
Materials: 316SS, optionally titanium.
Electrical:
Electrical connection: 4 pin, wet mateable, open face, pressure rated connector.
Isolation: 500Vrms circuit to case.
Supply voltage: 11-30vdc
Load Resistance: RL= 50 x (Vsupply-11) ohms.
Filters: high and low pass filters optionally available.
Cable jacket: polyurethane, optionally polyethylene.
Testing: Complete vibration and pressure testing services available. Please submit testing specifications for quote.
Optional communcation protocols/methods available.
Higher pressure ratings available.
